Product Name
Valve Actuator Mounting Kit — ISO 5211 Bracket & Stem Coupling, 304 Stainless
Product Summary
A 304 stainless steel valve actuator mounting kit — the ISO 5211 bridge that connects a pneumatic or electric actuator to a ball valve. It transmits torque to the stem and, on hot lines, sets the actuator back from the valve body to keep heat away from its seals and electronics.
ISO 5211 standard interface; the linkage is matched to your specific valve and actuator combination — tell us both when ordering.
ISO 9001 · CE · Manufacturer since 1999 · Made in Taiwan
Product Description
To automate a ball valve, the actuator’s output has to line up with the valve stem — squarely, with no play, and able to pass full torque. This valve actuator mounting kit is the part that makes that connection: a mounting bracket (the bridge) plus a stem coupler (the linkage), both in 304 stainless steel, built to the ISO 5211 interface.
Because the bracket follows the ISO 5211 standard, it pairs an ISO-standard pneumatic or electric actuator to the valve. The linkage that couples the stems is then matched to your specific valve and actuator sizes — tell us both when you order.
Two Jobs This Kit Does
This actuator mounting kit earns its place on two different jobs:
- Adaptation: connects an ISO 5211 actuator to a valve — including manual valves you want to automate, or a valve and actuator that don’t share a native mounting pattern.
- Heat stand-off: on steam and other hot lines, the bracket sets the actuator back from the valve body, opening an air gap that keeps heat away from the actuator’s seals and electronics.
Key Specifications
| Material | 304 stainless steel |
|---|---|
| Interface | ISO 5211 mounting standard |
| Function | Torque transmission and heat stand-off |
| Fit | Linkage matched to your valve and actuator combination — provide both when ordering |
| SKU | BL-304 |
Why It Matters
- Protects the actuator: keeps high-temperature media at a distance from the actuator’s seals and electronics.
- Automates the valve you already have: the ISO 5211 bridge lets you drive a manual valve without replacing it.
- Corrosion resistant: bracket and stem coupler are both 304 stainless steel.
Where It Is Used
- Non-standard mounting pairs — adapting a valve whose top flange isn’t a direct ISO 5211 match to the actuator you want to run it with.
- Manual-to-automated retrofits — adding a pneumatic or electric actuator onto a valve that was originally hand-operated.
- High-temperature lines — steam and other hot service, where the kit sets the actuator back from the valve body for extra air cooling.
Related Automation Parts
| Part | Use it for |
|---|---|
| Mounting kit (this page) | Mounting an actuator to a valve, or setting it back from the heat. |
| Electric actuator | The motor that drives the valve open and closed. |
| NAMUR solenoid valve | The pilot that controls a pneumatic actuator. |
| Extended handle | Manual operation, when powered automation isn’t needed. |
Frequently Asked Questions
What does an actuator mounting kit do?
It connects an actuator to a valve. The bracket bolts the actuator over the valve to the ISO 5211 pattern, and the linkage (a stem coupler) carries the actuator’s turning force to the valve stem.
Do I need a mounting kit, or can the actuator mount directly?
If the valve already has an ISO 5211 pad that matches the actuator’s flange and drive, the actuator can mount directly. You need the bracket and stem coupler when the two mounting patterns don’t match, when you are automating a manual valve, or when you want the actuator set back from a hot valve body.
Can it automate a manual valve?
Yes — that is one of its main uses. The kit lets you mount an actuator onto a manual valve you already have, so you can automate it without replacing the valve.
How does it protect the actuator on hot lines?
On steam and other high-temperature lines, the bracket sets the actuator back from the valve body. That gap gives the actuator extra air cooling and keeps it further from the heat reaching its seals and electronics.
What do you need to know to quote it?
Tell us your valve stem size and shape, the ISO 5211 flange size, and your actuator’s output specifications — that is what determines the matching linkage.
How do I get a price?
Send us the valve and actuator details and the quantity. We reply to every inquiry within 24 hours.
Sample Policy
We are happy to provide product samples for customers to evaluate quality or conduct testing. The process typically begins with a quotation based on the customer’s specifications.
If the pricing is acceptable, we can offer samples either free of charge or at a cost depending on the product type and availability.
Shipping fees are borne by the customer.
Order Process
After confirming the product requirements and other details with the customer, we will issue a Sales Confirmation for approval. Once confirmed, the customer is required to pay a 30% deposit to proceed with production.
When mass production is completed and the goods pass inspection, the customer must pay the remaining 70% balance before shipment is arranged.
